Phefon 10L Medical Cooler Box Temperature Display Support OEM

Phefon 10L Medical Cooler Box Temperature Display Support OEM

10L Medical Cooler Box

Phefon Medical Cooler Box

Temperature Display Medical Cooler Box

Place of Origin:

China

Brand Name:

PHEFON

Certification:

CE, ISO9001, ISO14001, ISO45001, ISO13485

Model Number:

FS-10L

Contact Us
Request A Quote
Product Details
Model No.:
FS-10L
Cold Time:
24~48hrs
External Dimensions:
370x280x298 Mm
Cooling Method:
Coolant Ice Pack
Mateirla:
Outer Shell And Liner Are PP
Temperature Range:
2-8℃ , 15~25℃,-25~-15℃
Internal Size:
270x173x203mm
Product:
Medical Cooler Box
Highlight:

10L Medical Cooler Box

,

Phefon Medical Cooler Box

,

Temperature Display Medical Cooler Box

Payment & Shipping Terms
Minimum Order Quantity
10
Price
Negotiable
Packaging Details
Carton/pallet Meet With All Ways To Export.
Delivery Time
5-7 Working Days
Payment Terms
T/T, Western Union, L/C
Supply Ability
3000 Units Per Month
Product Description

Product Description:

The Medical Cooler Box is a reliable solution for safely transporting temperature-sensitive medical supplies such as vaccines.

Designed to maintain cold temperatures for extended periods, this medical cool box with thermometer offers a cold time of 24 to 48 hours. This ensures that vaccines and other medical supplies remain within the required temperature range during transportation, safeguarding their efficacy.

The cooling method employed by this medical ice cold box is through a coolant ice pack. The ice pack helps regulate the internal temperature of the cooler box, keeping the contents consistently cold throughout the journey.

Constructed with high-quality materials, the outer shell and liner of the cooler box are made of PP (polypropylene), a durable and lightweight material known for its resistance to chemicals and impact. This ensures that the cooler box can withstand transportation challenges while protecting the delicate medical supplies inside.

Enhanced with high-density PU (Polyurethane) foam insulation, this portable vaccine transport cooler provides superior thermal insulation properties. The PU foam effectively traps and maintains the cold temperature within the cooler box, preventing heat transfer and external temperature fluctuations that could compromise the integrity of the medical supplies.

Whether you are a healthcare professional, medical courier, or humanitarian worker, the Medical Cooler Box is an essential tool for ensuring the safe and effective transport of temperature-sensitive medical supplies. Its reliable cooling performance, durable construction, and compact design make it an ideal choice for various medical transportation needs.

Features:

  • Product Name: Medical Cooler Box
  • Model: FS-10L
  • External Dimensions: 370x280x298 Mm
  • Customize Logo: Support
  • Temperature Display: Yes
  • Cooling Method: Coolant Ice Pack

Specifications:



Items
FS-6L
FS-10L
FS-12L
FS-18L
FS-35L
Cold chain type
Standard Cooler box
Standard Cooler box
Standard Cooler box
Standard Cooler box
Standard Cooler box
Capacity
6L
10L
12L
18L
35L
Weight Empity
1.95kg ±10%
2.4kg ±10%
2.93kg ±10%
2.8kg ±10%
4.5kg ±10%
External Surface material
PP
Internal lining
material
PP
Insulation material
PU(Polyurethane) CFC FREE FOAM
Insulation Thickness
≥40mm
≥45mm
≥40mm
≥25mm
≥25mm
External Diemnsion(mm)
325*235*250
370x280x298
425x262x305
425x262x305
570x305x365
Internal Dimension(mm)
240*140*165
270x173x203
325x170x225
363x203x244
475x245x270
Lid Type & Fixings
Unremovable
Unremovable
Unremovable
Unremovable
Unremovable
No.of Ice Packs Required
fixed ice packs / One set 0.4L ice packs




Applications:

With certifications such as CE, ISO9001, ISO14001, ISO45001, and ISO13485, you can trust that the PHEFON FS-10L Medical Cooler Box meets the highest quality standards. Its high-density PU foam insulation ensures reliable temperature control, with temperature ranges of 2-8℃, 15~25℃, and -25~-15℃ to accommodate a variety of medical products.



► How to use the medical cooler box:
* Before using, place the ice packs into the freezer until they are fully frozen (about 24 hours).

* If the configuration you choose is empty Ice packs, fill clean water in the ice pack first,then well sealed, then follow No.1 step to frozen.

* Place the frozen ice packs into the cooler box in the positions indicated, and close the lid.
* When the temperature inside of the box reached the ideal temperature, open the lid and place the contents to be kept cold in the cold transport container.

* Close the lid.
Notes:
When not using the cooler box, store the Ice Packs in the freezer please - then they will be ready for using just when you want them next time.

Phefon 10L Medical Cooler Box Temperature Display Support OEM 0Phefon 10L Medical Cooler Box Temperature Display Support OEM 1Phefon 10L Medical Cooler Box Temperature Display Support OEM 2Phefon 10L Medical Cooler Box Temperature Display Support OEM 3

Support and Services:

Our Product Technical Support team is dedicated to assisting you with any questions or issues you may have regarding your Medical Cooler Box. Whether you need help with setup, troubleshooting, or maintenance, our team is here to provide expert guidance and support.

In addition to technical support, we also offer a range of services to ensure that your Medical Cooler Box is always functioning at its best. These services may include regular maintenance checks, product upgrades, and repair services to keep your cooler box in top condition.
